One-Touch Fastener - Ball Clamping 33924 - 33925
What is...
Features
Operating Principle
Four ball bearings clamp onto the clamping pin (33923), the wedge shape of the pin draws the panels together during clamping.
Operating Instructions
- Engage clamp over pin, no need to push button, a positive "click" is heard.
- Securing balls are locked and panel fastened.
- To release; while pushing down on release button, lift panel from pin - panel is released.
Installation
Dimensions
Best Practice
For highly accurate locating, use locating pins 36340 or 36341. Repeatability of ±0.25 is achievable.
Applications
Changes of trays and containers on conveyers
Securing sliding elements such as drawers
