Magnetic Catches
hermetically sealed
E5300 Magnetic Catches - Hermetically Sealed
for clean room and medical environments, material: Polyacetal
Order No.
E5300.AC0010
Type
Magnet
Magnetic force
kgf
3
Finish
White
Weight
g
21.0
£ 8.40 per unit (click for quantity discounts)
Ready to despatch 0
Need more? Manufactured within 10 working days from order. Typical UK delivery charge: £13.50. Confirmed at checkout.
Need more? Manufactured within 10 working days from order. Typical UK delivery charge: £13.50. Confirmed at checkout.
| Units | Price/unit after discount | Applied Discount |
| 1-19 | £ 8.40 | 0% |
| 20-49 | £ 7.56 | 10% |
| 50-99 | £ 7.14 | 15% |
| 100-499 | £ 6.30 | 25% |
| 500+ | £ 5.46 | 35% |
Technical & Application
Material
Body: polyacetal.
Magnet: neodymium.
Strike plate: stainless steel, AISI 304, specially treated for magnetism; or sealed strike plate in polyacetal.
Technical Notes
For clean room and medical environment, hermetically sealed.
