70820 Eight Lobed Knobs

with grub screw, material: Thermoplastic

Download product datasheet

Download FREE CAD

Alternative products you may wish to consider

Eight Lobed Knobs

Eight Lobed Knobs
with grub screw

Eight Lobed Knobs - Thermoplastic. 25 - M 4 - 15 - 13

70820.W0021

d₁

25

d₂

M 4

l₁

15

d₃

13

h₁

17

h₂

8

Weight g

7

£ 1.00 per unit (click for quantity discounts)

Eight Lobed Knobs - Thermoplastic. 25 - M 5 - 25 - 13

70820.W0023

d₁

25

d₂

M 5

l₁

25

d₃

13

h₁

17

h₂

8

Weight g

9

£ 1.05 per unit (click for quantity discounts)

Eight Lobed Knobs - Thermoplastic. 35 - M 6 - 15 - 18

70820.W0031

d₁

35

d₂

M 6

l₁

15

d₃

18

h₁

20

h₂

8

Weight g

19

£ 1.17 per unit (click for quantity discounts)

Eight Lobed Knobs - Thermoplastic. 35 - M 6 - 25 - 18

70820.W0032

d₁

35

d₂

M 6

l₁

25

d₃

18

h₁

20

h₂

8

Weight g

20

£ 1.19 per unit (click for quantity discounts)

Eight Lobed Knobs - Thermoplastic. 35 - M 6 - 35 - 18

70820.W0033

d₁

35

d₂

M 6

l₁

35

d₃

18

h₁

20

h₂

8

Weight g

22

£ 1.32 per unit (click for quantity discounts)

Eight Lobed Knobs - Thermoplastic. 35 - M 8 - 25 - 18

70820.W0035

d₁

35

d₂

M 8

l₁

25

d₃

18

h₁

20

h₂

8

Weight g

26

£ 1.46 per unit (click for quantity discounts)

Eight Lobed Knobs - Thermoplastic. 35 - M 8 - 40 - 18

70820.W0036

d₁

35

d₂

M 8

l₁

40

d₃

18

h₁

20

h₂

8

Weight g

29

£ 1.55 per unit (click for quantity discounts)

Eight Lobed Knobs - Thermoplastic. 35 - M10 - 30 - 18

70820.W0037

d₁

35

d₂

M10

l₁

30

d₃

18

h₁

20

h₂

8

Weight g

35

£ 1.77 per unit (click for quantity discounts)

Eight Lobed Knobs - Thermoplastic. 45 - M 8 - 20 - 22

70820.W0041

d₁

45

d₂

M 8

l₁

20

d₃

22

h₁

26

h₂

12

Weight g

37

£ 1.68 per unit (click for quantity discounts)

Eight Lobed Knobs - Thermoplastic. 45 - M 8 - 25 - 22

70820.W0042

d₁

45

d₂

M 8

l₁

25

d₃

22

h₁

26

h₂

12

Weight g

38

£ 1.68 per unit (click for quantity discounts)

Eight Lobed Knobs - Thermoplastic. 45 - M 8 - 30 - 22

70820.W0043

d₁

45

d₂

M 8

l₁

30

d₃

22

h₁

26

h₂

12

Weight g

39

£ 1.72 per unit (click for quantity discounts)

Eight Lobed Knobs - Thermoplastic. 45 - M10 - 30 - 22

70820.W0046

d₁

45

d₂

M10

l₁

30

d₃

22

h₁

26

h₂

12

Weight g

51

£ 1.87 per unit (click for quantity discounts)

Eight Lobed Knobs - Thermoplastic. 45 - M10 - 40 - 22

70820.W0047

d₁

45

d₂

M10

l₁

40

d₃

22

h₁

26

h₂

12

Weight g

54

£ 1.93 per unit (click for quantity discounts)

Eight Lobed Knobs - Thermoplastic. 55 - M 8 - 20 - 25

70820.W0051

d₁

55

d₂

M 8

l₁

20

d₃

25

h₁

29

h₂

15

Weight g

50

£ 1.99 per unit (click for quantity discounts)

Eight Lobed Knobs - Thermoplastic. 55 - M 8 - 30 - 25

70820.W0052

d₁

55

d₂

M 8

l₁

30

d₃

25

h₁

29

h₂

15

Weight g

53

£ 1.99 per unit (click for quantity discounts)

Eight Lobed Knobs - Thermoplastic. 55 - M 8 - 40 - 25

70820.W0053

d₁

55

d₂

M 8

l₁

40

d₃

25

h₁

29

h₂

15

Weight g

56

£ 2.01 per unit (click for quantity discounts)

Eight Lobed Knobs - Thermoplastic. 55 - M10 - 20 - 25

70820.W0054

d₁

55

d₂

M10

l₁

20

d₃

25

h₁

29

h₂

15

Weight g

57

£ 2.10 per unit (click for quantity discounts)

Eight Lobed Knobs - Thermoplastic. 55 - M12 - 30 - 25

70820.W0057

d₁

55

d₂

M12

l₁

30

d₃

25

h₁

29

h₂

15

Weight g

83

£ 2.42 per unit (click for quantity discounts)

Eight Lobed Knobs - Thermoplastic. 25 - M 4 - 15 - 13

70820.W0021

d₁

25

d₂

M 4

l₁

15

d₃

13

h₁

17

h₂

8

Weight g

7

£ 1.00 per unit (click for quantity discounts)

Eight Lobed Knobs - Thermoplastic. 25 - M 5 - 25 - 13

70820.W0023

d₁

25

d₂

M 5

l₁

25

d₃

13

h₁

17

h₂

8

Weight g

9

£ 1.05 per unit (click for quantity discounts)

Eight Lobed Knobs - Thermoplastic. 35 - M 6 - 15 - 18

70820.W0031

d₁

35

d₂

M 6

l₁

15

d₃

18

h₁

20

h₂

8

Weight g

19

£ 1.17 per unit (click for quantity discounts)

Eight Lobed Knobs - Thermoplastic. 35 - M 6 - 25 - 18

70820.W0032

d₁

35

d₂

M 6

l₁

25

d₃

18

h₁

20

h₂

8

Weight g

20

£ 1.19 per unit (click for quantity discounts)

Eight Lobed Knobs - Thermoplastic. 35 - M 6 - 35 - 18

70820.W0033

d₁

35

d₂

M 6

l₁

35

d₃

18

h₁

20

h₂

8

Weight g

22

£ 1.32 per unit (click for quantity discounts)

Eight Lobed Knobs - Thermoplastic. 35 - M 8 - 25 - 18

70820.W0035

d₁

35

d₂

M 8

l₁

25

d₃

18

h₁

20

h₂

8

Weight g

26

£ 1.46 per unit (click for quantity discounts)

Eight Lobed Knobs - Thermoplastic. 35 - M 8 - 40 - 18

70820.W0036

d₁

35

d₂

M 8

l₁

40

d₃

18

h₁

20

h₂

8

Weight g

29

£ 1.55 per unit (click for quantity discounts)

Eight Lobed Knobs - Thermoplastic. 35 - M10 - 30 - 18

70820.W0037

d₁

35

d₂

M10

l₁

30

d₃

18

h₁

20

h₂

8

Weight g

35

£ 1.77 per unit (click for quantity discounts)

Eight Lobed Knobs - Thermoplastic. 45 - M 8 - 20 - 22

70820.W0041

d₁

45

d₂

M 8

l₁

20

d₃

22

h₁

26

h₂

12

Weight g

37

£ 1.68 per unit (click for quantity discounts)

Eight Lobed Knobs - Thermoplastic. 45 - M 8 - 25 - 22

70820.W0042

d₁

45

d₂

M 8

l₁

25

d₃

22

h₁

26

h₂

12

Weight g

38

£ 1.68 per unit (click for quantity discounts)

Eight Lobed Knobs - Thermoplastic. 45 - M 8 - 30 - 22

70820.W0043

d₁

45

d₂

M 8

l₁

30

d₃

22

h₁

26

h₂

12

Weight g

39

£ 1.72 per unit (click for quantity discounts)

Eight Lobed Knobs - Thermoplastic. 45 - M10 - 30 - 22

70820.W0046

d₁

45

d₂

M10

l₁

30

d₃

22

h₁

26

h₂

12

Weight g

51

£ 1.87 per unit (click for quantity discounts)

Eight Lobed Knobs - Thermoplastic. 45 - M10 - 40 - 22

70820.W0047

d₁

45

d₂

M10

l₁

40

d₃

22

h₁

26

h₂

12

Weight g

54

£ 1.93 per unit (click for quantity discounts)

Eight Lobed Knobs - Thermoplastic. 55 - M 8 - 20 - 25

70820.W0051

d₁

55

d₂

M 8

l₁

20

d₃

25

h₁

29

h₂

15

Weight g

50

£ 1.99 per unit (click for quantity discounts)

Eight Lobed Knobs - Thermoplastic. 55 - M 8 - 30 - 25

70820.W0052

d₁

55

d₂

M 8

l₁

30

d₃

25

h₁

29

h₂

15

Weight g

53

£ 1.99 per unit (click for quantity discounts)

Eight Lobed Knobs - Thermoplastic. 55 - M 8 - 40 - 25

70820.W0053

d₁

55

d₂

M 8

l₁

40

d₃

25

h₁

29

h₂

15

Weight g

56

£ 2.01 per unit (click for quantity discounts)

Eight Lobed Knobs - Thermoplastic. 55 - M10 - 20 - 25

70820.W0054

d₁

55

d₂

M10

l₁

20

d₃

25

h₁

29

h₂

15

Weight g

57

£ 2.10 per unit (click for quantity discounts)

Eight Lobed Knobs - Thermoplastic. 55 - M12 - 30 - 25

70820.W0057

d₁

55

d₂

M12

l₁

30

d₃

25

h₁

29

h₂

15

Weight g

83

£ 2.42 per unit (click for quantity discounts)



Select all

d₁

d₂

l₁

d₃

h₁

h₂

Weight g

Price & Availability	Article	d1	d2	l1	d3	h1	h2	Weight g
	70820.W0021	25	M 4	15	13	17	8	7
£ 1.00 per unit (click for quantity discounts) Ready to despatch 126 Need more? Manufactured within 10 working days from order. Typical UK delivery charge: £13.50. Confirmed at checkout. Buy more & save with our quantity discounts Units Price/unit after discount Applied Discount 1-49 £ 1.00 0% 50-99 £ 0.90 10% 100-249 £ 0.85 15% 250-499 £ 0.80 20% 500+ £ 0.75 25% d1 25 d2 M 4 l1 15 d3 13 h1 17 h2 8 Weight g 7 more info »
	70820.W0023	25	M 5	25	13	17	8	9
£ 1.05 per unit (click for quantity discounts) Ready to despatch 30 Need more? Manufactured within 10 working days from order. Typical UK delivery charge: £13.50. Confirmed at checkout. Buy more & save with our quantity discounts Units Price/unit after discount Applied Discount 1-49 £ 1.05 0% 50-99 £ 0.95 10% 100-249 £ 0.89 15% 250-499 £ 0.84 20% 500+ £ 0.79 25% d1 25 d2 M 5 l1 25 d3 13 h1 17 h2 8 Weight g 9 more info »
	70820.W0031	35	M 6	15	18	20	8	19
£ 1.17 per unit (click for quantity discounts) Ready to despatch 19 Need more? Manufactured within 10 working days from order. Typical UK delivery charge: £13.50. Confirmed at checkout. Buy more & save with our quantity discounts Units Price/unit after discount Applied Discount 1-49 £ 1.17 0% 50-99 £ 1.05 10% 100-249 £ 0.99 15% 250-499 £ 0.94 20% 500+ £ 0.88 25% d1 35 d2 M 6 l1 15 d3 18 h1 20 h2 8 Weight g 19 more info »
	70820.W0032	35	M 6	25	18	20	8	20
£ 1.19 per unit (click for quantity discounts) Ready to despatch 43 Need more? Manufactured within 10 working days from order. Typical UK delivery charge: £13.50. Confirmed at checkout. Buy more & save with our quantity discounts Units Price/unit after discount Applied Discount 1-49 £ 1.19 0% 50-99 £ 1.07 10% 100-249 £ 1.01 15% 250-499 £ 0.95 20% 500+ £ 0.89 25% d1 35 d2 M 6 l1 25 d3 18 h1 20 h2 8 Weight g 20 more info »
	70820.W0033	35	M 6	35	18	20	8	22
£ 1.32 per unit (click for quantity discounts) Ready to despatch 5 Need more? Manufactured within 10 working days from order. Typical UK delivery charge: £13.50. Confirmed at checkout. Buy more & save with our quantity discounts Units Price/unit after discount Applied Discount 1-49 £ 1.32 0% 50-99 £ 1.19 10% 100-249 £ 1.12 15% 250-499 £ 1.06 20% 500+ £ 0.99 25% d1 35 d2 M 6 l1 35 d3 18 h1 20 h2 8 Weight g 22 more info »
	70820.W0035	35	M 8	25	18	20	8	26
£ 1.46 per unit (click for quantity discounts) Ready to despatch 33 Need more? Manufactured within 10 working days from order. Typical UK delivery charge: £13.50. Confirmed at checkout. Buy more & save with our quantity discounts Units Price/unit after discount Applied Discount 1-49 £ 1.46 0% 50-99 £ 1.31 10% 100-249 £ 1.24 15% 250-499 £ 1.17 20% 500+ £ 1.10 25% d1 35 d2 M 8 l1 25 d3 18 h1 20 h2 8 Weight g 26 more info »
	70820.W0036	35	M 8	40	18	20	8	29
£ 1.55 per unit (click for quantity discounts) Ready to despatch 10 Need more? Manufactured within 10 working days from order. Typical UK delivery charge: £13.50. Confirmed at checkout. Buy more & save with our quantity discounts Units Price/unit after discount Applied Discount 1-49 £ 1.55 0% 50-99 £ 1.40 10% 100-249 £ 1.32 15% 250-499 £ 1.24 20% 500+ £ 1.16 25% d1 35 d2 M 8 l1 40 d3 18 h1 20 h2 8 Weight g 29 more info »
	70820.W0037	35	M10	30	18	20	8	35
£ 1.77 per unit (click for quantity discounts) Ready to despatch 3 Need more? Manufactured within 10 working days from order. Typical UK delivery charge: £13.50. Confirmed at checkout. Buy more & save with our quantity discounts Units Price/unit after discount Applied Discount 1-49 £ 1.77 0% 50-99 £ 1.59 10% 100-249 £ 1.50 15% 250-499 £ 1.42 20% 500+ £ 1.33 25% d1 35 d2 M10 l1 30 d3 18 h1 20 h2 8 Weight g 35 more info »
	70820.W0041	45	M 8	20	22	26	12	37
£ 1.68 per unit (click for quantity discounts) Ready to despatch 50 Need more? Manufactured within 10 working days from order. Typical UK delivery charge: £13.50. Confirmed at checkout. Buy more & save with our quantity discounts Units Price/unit after discount Applied Discount 1-49 £ 1.68 0% 50-99 £ 1.51 10% 100-249 £ 1.43 15% 250-499 £ 1.34 20% 500+ £ 1.26 25% d1 45 d2 M 8 l1 20 d3 22 h1 26 h2 12 Weight g 37 more info »
	70820.W0042	45	M 8	25	22	26	12	38
£ 1.68 per unit (click for quantity discounts) Ready to despatch 13 Need more? Manufactured within 10 working days from order. Typical UK delivery charge: £13.50. Confirmed at checkout. Buy more & save with our quantity discounts Units Price/unit after discount Applied Discount 1-49 £ 1.68 0% 50-99 £ 1.51 10% 100-249 £ 1.43 15% 250-499 £ 1.34 20% 500+ £ 1.26 25% d1 45 d2 M 8 l1 25 d3 22 h1 26 h2 12 Weight g 38 more info »
	70820.W0043	45	M 8	30	22	26	12	39
£ 1.72 per unit (click for quantity discounts) Ready to despatch 10 Need more? Manufactured within 10 working days from order. Typical UK delivery charge: £13.50. Confirmed at checkout. Buy more & save with our quantity discounts Units Price/unit after discount Applied Discount 1-49 £ 1.72 0% 50-99 £ 1.55 10% 100-249 £ 1.46 15% 250-499 £ 1.38 20% 500+ £ 1.29 25% d1 45 d2 M 8 l1 30 d3 22 h1 26 h2 12 Weight g 39 more info »
	70820.W0046	45	M10	30	22	26	12	51
£ 1.87 per unit (click for quantity discounts) Ready to despatch 15 Need more? Manufactured within 10 working days from order. Typical UK delivery charge: £13.50. Confirmed at checkout. Buy more & save with our quantity discounts Units Price/unit after discount Applied Discount 1-49 £ 1.87 0% 50-99 £ 1.68 10% 100-249 £ 1.59 15% 250-499 £ 1.50 20% 500+ £ 1.40 25% d1 45 d2 M10 l1 30 d3 22 h1 26 h2 12 Weight g 51 more info »
	70820.W0047	45	M10	40	22	26	12	54
£ 1.93 per unit (click for quantity discounts) Ready to despatch 2 Need more? Manufactured within 10 working days from order. Typical UK delivery charge: £13.50. Confirmed at checkout. Buy more & save with our quantity discounts Units Price/unit after discount Applied Discount 1-49 £ 1.93 0% 50-99 £ 1.74 10% 100-249 £ 1.64 15% 250-499 £ 1.54 20% 500+ £ 1.45 25% d1 45 d2 M10 l1 40 d3 22 h1 26 h2 12 Weight g 54 more info »
	70820.W0051	55	M 8	20	25	29	15	50
£ 1.99 per unit (click for quantity discounts) Ready to despatch 5 Need more? Manufactured within 10 working days from order. Typical UK delivery charge: £13.50. Confirmed at checkout. Buy more & save with our quantity discounts Units Price/unit after discount Applied Discount 1-49 £ 1.99 0% 50-99 £ 1.79 10% 100-249 £ 1.69 15% 250-499 £ 1.59 20% 500+ £ 1.49 25% d1 55 d2 M 8 l1 20 d3 25 h1 29 h2 15 Weight g 50 more info »
	70820.W0052	55	M 8	30	25	29	15	53
£ 1.99 per unit (click for quantity discounts) Ready to despatch 44 Need more? Manufactured within 10 working days from order. Typical UK delivery charge: £13.50. Confirmed at checkout. Buy more & save with our quantity discounts Units Price/unit after discount Applied Discount 1-49 £ 1.99 0% 50-99 £ 1.79 10% 100-249 £ 1.69 15% 250-499 £ 1.59 20% 500+ £ 1.49 25% d1 55 d2 M 8 l1 30 d3 25 h1 29 h2 15 Weight g 53 more info »
	70820.W0053	55	M 8	40	25	29	15	56
£ 2.01 per unit (click for quantity discounts) Ready to despatch 15 Need more? Manufactured within 10 working days from order. Typical UK delivery charge: £13.50. Confirmed at checkout. Buy more & save with our quantity discounts Units Price/unit after discount Applied Discount 1-49 £ 2.01 0% 50-99 £ 1.81 10% 100-249 £ 1.71 15% 250-499 £ 1.61 20% 500+ £ 1.51 25% d1 55 d2 M 8 l1 40 d3 25 h1 29 h2 15 Weight g 56 more info »
	70820.W0054	55	M10	20	25	29	15	57
£ 2.10 per unit (click for quantity discounts) Ready to despatch 22 Need more? Manufactured within 10 working days from order. Typical UK delivery charge: £13.50. Confirmed at checkout. Buy more & save with our quantity discounts Units Price/unit after discount Applied Discount 1-49 £ 2.10 0% 50-99 £ 1.89 10% 100-249 £ 1.79 15% 250-499 £ 1.68 20% 500+ £ 1.58 25% d1 55 d2 M10 l1 20 d3 25 h1 29 h2 15 Weight g 57 more info »
	70820.W0057	55	M12	30	25	29	15	83
£ 2.42 per unit (click for quantity discounts) Ready to despatch 70 Need more? Manufactured within 10 working days from order. Typical UK delivery charge: £13.50. Confirmed at checkout. Buy more & save with our quantity discounts Units Price/unit after discount Applied Discount 1-49 £ 2.42 0% 50-99 £ 2.18 10% 100-249 £ 2.06 15% 250-499 £ 1.94 20% 500+ £ 1.82 25% d1 55 d2 M12 l1 30 d3 25 h1 29 h2 15 Weight g 83 more info »
