Lever Catches
finger tip control
E2002 Lever Catches
finger tip control - stainless steel, material: Stainless steel
Order No.
E2002.AC0530
Finish
Stainless Steel
Holding force
kg
20
Weight
g
85
£ 113.04 per unit (click for quantity discounts)
Ready to despatch 71
Need more? Manufactured within 10 working days from order. Typical UK delivery charge: £13.50. Confirmed at checkout.
Need more? Manufactured within 10 working days from order. Typical UK delivery charge: £13.50. Confirmed at checkout.
| Units | Price/unit after discount | Applied Discount |
| 1-4 | £ 113.04 | 0% |
| 5-9 | £ 107.39 | 5% |
| 10-19 | £ 101.74 | 10% |
| 20-49 | £ 96.08 | 15% |
| 50+ | £ 84.78 | 25% |
Technical & Application
Material
Stainless steel, AISI 316.
Technical Notes
Screws not supplied.
This lever catch is designed for use on door without knob or handle, to provide concealed latching and securing of panel.
Product Datasheets
Application images
