Disk Dampers
bi-directional
Q3220 Disk Dampers
bi-directional - continuous rotation - up to 87 Kgf.cm, material: Steel
Alternative products you may wish to consider
£ 41.10 per unit (click for quantity discounts)
£ 44.24 per unit (click for quantity discounts)
Damping torque
kgf/cm
Weight capacity
max.
kg
Weight
g
| Price & Availability | Article | Damping torque kgf/cm | Weight capacity max. kg | Weight g | ||||||||||||||||||
| Q3220.AC0067 | 67 | 0.12 | 92 | |||||||||||||||||||
£ 41.10 per unit (click for quantity discounts) Ready to despatch 0 Need more? Manufactured within 10 working days from order. Typical UK delivery charge: £13.50. Confirmed at checkout.
Damping torque
kgf/cm 67 Weight capacity
max.
kg 0.12 Weight
g 92 | ||||||||||||||||||||||
| Q3220.AC0087 | 87 | 0.12 | 112 | |||||||||||||||||||
£ 44.24 per unit (click for quantity discounts) Ready to despatch 5 Need more? Manufactured within 10 working days from order. Typical UK delivery charge: £13.50. Confirmed at checkout.
Damping torque
kgf/cm 87 Weight capacity
max.
kg 0.12 Weight
g 112 | ||||||||||||||||||||||
Technical & Application
Material
Body: steel
Socket: nylon with glass fibre
Operating fluid: silicone oil.
Tips
For graphs of torque at varying temperature and speed, see Torque Closing Speed Graphs earlier in this section.
Damper can only take torque load.
Important Notes
Temperature range -10°c to +50°c.
Rotational speed 50 rpm max.
Cycle rate 12 cycles/min.
External support for shaft required.
Product Datasheets
