Adj. Clamping Levers
female, inner parts s/s
74440 Adjustable Clamping Levers
threaded bore, inner parts stainless steel, material: Die cast zinc
Order No.
74440.W0624
Colour
Black
d1
30
d2
M16
d3
23.0
h1
50.5
h2
12.0
h3
5.0
h4
76.0
l2
108
t
≤
22
Weight
g
269
£ 29.06 per unit (click for quantity discounts)
Ready to despatch 0
Need more? Manufactured within 10 working days from order. Typical UK delivery charge: £13.50. Confirmed at checkout.
Need more? Manufactured within 10 working days from order. Typical UK delivery charge: £13.50. Confirmed at checkout.
| Units | Price/unit after discount | Applied Discount |
| 1-9 | £ 29.06 | 0% |
| 10-19 | £ 26.15 | 10% |
| 20-49 | £ 24.70 | 15% |
| 50-99 | £ 23.25 | 20% |
| 100+ | £ 21.80 | 25% |
Technical & Application
Material
Handle: die-cast zinc,
- Orange RAL 2004
- Black RAL 9005
Inner parts: stainless steel 1,4305 (AISI 303).
Threaded part: stainless steel 1.4305. (AISI 303).
Technical Notes
By lifting the lever, the serrations are disengaged. The handle can be positioned by the serrations, and the threaded insert can be exchanged. Upon releasing the handle, the serrations are automatically re-engaged. The collar screw is torx head.
Tips
Suitable for medical and chemical industry applications.
