S2404 Lift-Off Hinges - Off-Set

Name: S2404.AW0164
Brand: WC
SKU: S2404.AW0164
Price: 1.95 EUR
Availability: InStock

bolt-on - zinc, material: Die cast zinc

Article properties

Order No.

S2404.AW0164

Type

Two

Hand

Left

l₁

25.5

w₁

20.5

d₁

M 4

h₁

10.0

h₂

5.5

l₂

l₃

l₄

l₅

w₂

w₃

9.4

F_x N

270

See full product selection

£ 1.95 per unit (click for quantity discounts)

Ready to despatch 66
Need more? Please call us.

Buy more & save with our quantity discounts

Units	Price/unit after discount	Applied Discount
1-19	£ 1.95	0%
20-49	£ 1.76	10%
50-99	£ 1.66	15%
100-499	£ 1.46	25%
500+	£ 1.27	35%

Download product datasheet

Download FREE CAD

Technical & Application

Material

Type one: Body: die cast zinc, black powder coated.
Bushing: polyamide.
Type two: Body: die cast zinc, black powder coated.
Natural unfinished available on request, subject to minimum order quantity.

Technical Notes

Lift off hinge for plain/flush mounted doors. Concealed mounting screws prevent external access to the hinge. Opening angle 180°.
