XYZ Xpansion Pins
press-fit
12085.3 One-Touch Flex Locator Bushings
material: Steel
Alternative products you may wish to consider
Size
6
d1
28
d2
12.5
d3
21.5
d4
13.5
d5
28
d6
3.4
d7
M 3x0,5
h1
5.5
h2
8
h3
2
h4
15
h5
6
Weight
g
20
£ 57.25 per unit (click for quantity discounts)
Size
8
d1
32
d2
17
d3
25.5
d4
18.0
d5
32
d6
3.4
d7
M 3x0,5
h1
6.5
h2
10
h3
3
h4
18
h5
7
Weight
g
32
£ 58.41 per unit (click for quantity discounts)
Size
d1
d2
d3
d4
d5
d6
d7
h1
h2
h3
h4
h5
Weight
g
| Price & Availability | Article | Size | d1 | d2 | d3 | d4 | d5 | d6 | d7 | h1 | h2 | h3 | h4 | h5 | Weight g | ||||||||||||||||||
| 12085.W0506 | 6 | 28 | 12.5 | 21.5 | 13.5 | 28 | 3.4 | M 3x0,5 | 5.5 | 8 | 2 | 15 | 6 | 20 | |||||||||||||||||||
£ 57.25 per unit (click for quantity discounts) Ready to despatch 0 Need more? Manufactured within 21 working days from order. Typical UK delivery charge: £13.50. Confirmed at checkout.
Size 6 d1 28 d2 12.5 d3 21.5 d4 13.5 d5 28 d6 3.4 d7 M 3x0,5 h1 5.5 h2 8 h3 2 h4 15 h5 6 Weight
g 20 | |||||||||||||||||||||||||||||||||
| 12085.W0508 | 8 | 32 | 17 | 25.5 | 18.0 | 32 | 3.4 | M 3x0,5 | 6.5 | 10 | 3 | 18 | 7 | 32 | |||||||||||||||||||
£ 58.41 per unit (click for quantity discounts) Ready to despatch 0 Need more? Manufactured within 5 working days from order. Typical UK delivery charge: £13.50. Confirmed at checkout.
Size 8 d1 32 d2 17 d3 25.5 d4 18.0 d5 32 d6 3.4 d7 M 3x0,5 h1 6.5 h2 10 h3 3 h4 18 h5 7 Weight
g 32 | |||||||||||||||||||||||||||||||||
Technical & Application
Material
Stainless steel (AISI 304, 1.4301).
Technical Notes
Clamping plates for spiral cam clamp, part no. 12108. Use plates to avoid any deformation to workpiece during clamping.
Product Datasheets
Application images
